Description

rear of door, -O.E.M.-, all 2nd design: 2 wires connect to each door ajar switch, each switch has 2 flat male blade type terminal connections (2 required per car)

Additional information

Lectric Limited Part #: 06258295
OEM Part #: 06258295
WebID Part #: id-06258295-0004
Weight: 0.1 lbs

You have not selected a vehicle

Also fits: This fit is only a guideline. Please verify the fit by entering your specific vehicle.

Make	Model	Years
CHEVROLET	CORVETTE	1973 - 1982

TECH NOTES:

Our switch is manufactured per the original GM blueprint specifications and utilizes a 3/8"-24 Type "C" thread. Per GM specifications, our switch is designed to cut its own threads when installed into a .348" diameter non-threaded hole in the switch mounting/backing plate.

Our switch should easily fit, and screw into an original mounting/backing plate.

However, it has come to our attention that there my be problems when installing our switch into some (or all) of the currently reproduced mounting/backing plates. The reason is that these reproduction mounting/backing plates have a smaller hole size and are pre-threaded.
