Description

-O.E.M. made in U.S.A. using original GM tooling-, all big block

Additional information

Lectric Limited Part #: TCS4453
OEM Part #: 01114453
WebID Part #: id-tcs4453-0004
Weight: 0.4 lbs

You have not selected a vehicle

Also fits: This fit is only a guideline. Please verify the fit by entering your specific vehicle.

Make	Model	Years
CHEVROLET	CORVETTE	1972
CHEVROLET	CAMARO	1972
CHEVROLET	CHEVELLE/EL CAMINO/MONTE CARLO/MALIBU	1972
CHEVROLET	FULLSIZE 1958 & UP	1972

TECH NOTES:

Introduced in 1970, the Transmission Controlled Spark (T.C.S.) System controls exhaust emissions by eliminating vacuum advance in the lower forward gears, while at operating temperature.

Often referred to as a T.C.S. Solenoid, this solenoid controls the vacuum to the distributor's vacuum advance unit. This solenoid determines when, and how much, vacuum to release.

Typically, a vacuum line from the carburetor enters the solenoid and another vacuum line exits the solenoid to the distributor vacuum advance unit (some applications have multiple inlet and outlet lines).

This solenoid also relies on an electrical signal provided by other T.C.S. system switches/senders via an electrical connection on the back or side of the solenoid (the Engine Harness or T.C.S. Harness plugs into this connection).
