Description

located on passenger side cylinder head, -O.E.M. replacement made in U.S.A.-, V8, with factory gauges & 2 terminal plastic connector to switch in passenger side cylinder head

Additional information

Lectric Limited Part #: 06489785
OEM Part #: 06489785
WebID Part #: id-06489785-0014
Weight: 0.1 lbs

You have not selected a vehicle

Also fits: This fit is only a guideline. Please verify the fit by entering your specific vehicle.

Make	Model	Years
CHEVROLET	FULLSIZE 1958 & UP	1970
CHEVROLET	CORVETTE	1970 - 1974
CHEVROLET	CAMARO	1970 - 1971
CHEVROLET	CHEVELLE/EL CAMINO/MONTE CARLO/MALIBU	1970
CHEVROLET	CHEVY II/NOVA	1970

TECH NOTES:

Introduced in 1970, the Transmission Controlled Spark (T.C.S.) System controls exhaust emissions by eliminating vacuum advance in the lower forward gears, while at operating temperature.

This Transmission Controlled Spark (T.C.S.) Switch is one component of the emission system. It screws into the cylinder head to detect coolant temperature. When activated, this switch is designed to override this system, until the engine temperature reaches a set temperature. This allows vacuum advance in all gears, thereby preventing stalling after starting.
